- Product Name: Long Arm Extra Heavy Duty Unison Feed Lockstitch Sewing Machine
- Model NO.: FX-158
- Origin: Zhejiang,China
- Packing: Wooden Case
- Brand Name: FOXSEW
-
Product Details: Long Arm Extra Heavy Duty Unison Feed Lockstitch Sewing Machine
FOXSEW 158 Long Arm Flat Bed Extra Heavy Duty Compound Feed Sewing Machine
FX-158-2 Twin Needle Flat Bed Extra Heavy Duty Triple Feed Sewing machine
Applications: Furniture upholstery, Leather, sofa, Car seat, Cushion, Air bag, Container bags, Wide textile lifting slings & cargo lashing strap, Safety belts and Harness, Sails, Tents, Awnings, Canopies, Military Parachutes, Crane slings, Spray hood, Carpets, Luggage, Industrial safety products, Construction Barriers, Field covers, Divider curtains, Protective clothes etc.
Working Video 1: www.foxsew.com/company-video/double-needle-walking-foot-sewing-machine-for-leather-upholstery-and-webbings-548.html
Working Video 2: www.foxsew.com/company-video/long-arm-double-needle-walking-foot-leather-upholstery-sewing-machine-550.html
Working Video 3: www.foxsew.com/company-video/heavy-duty-big-bag-container-belts-sewing-machine-496.html
Working Vidoe 4: www.foxsew.com/company-video/flat-bed-walking-foot-heavy-duty-sewing-machine-for-container-bags-503.html
Features: This model is the king size of extra heavy materials compound feed lockstitch sewing machine of FOXSEW brand, it adopts vertical rotating hook, sliding lever thread take-up. We divide it into single-needle and double-needles. It adopts Synchronic feeding of needle bar and feed dog. The comprehensive performance of whole machine is so strong, especially includes these aspects: smooth drive train, low noise, large operation space, we also installed the clutch device to pretend the rotating hook from overloading, insure the safety of products and rotating hook. Convenient operation of pedal type reverse-feed, push-button type needling-distance regulating mechanism, adopts concealed bobbin winder, equipped with automatic lubrication rotary horizontal hook, it can reduce the frequency of changing the baseline when sewing thick seaming work piece. It is suitable for leather, artificial leather, Canvas, nylon chemical fibber, synthetic material, rubber and so on which is extra heavy materials, used for sewing sails and tents, cushion, sofa, beach umbrella, truck’s hook etc.
Specifications:
Model |
FX-158 |
FX-158-2 |
Number of Needle |
1 |
2 |
Max. Sewing Speed |
1200 r.p.m |
|
Stitch Length |
0-10 mm |
|
Needle Bar Stroke |
46.8 mm |
|
Presser Foot Lift |
By hand: 12 mm By Knee: 21.5 mm |
|
Needle type |
DD*1 21#28# |
|
Rotating Hook |
Horizontal Fall Rotation Extra Large Rotary Hook |
|
Presser Foot Alternation |
6-19 mm |
|
Lubrication |
Manual Lubrication |
|
Scale |
Sliding Lever Type |
|
Needle Gauge |
Standard 9.5mm |
|
Operating Space |
600*160 mm |
|
Motor |
550W Clutch Motor 1400 r.p.m |
-
Product Images: Long Arm Extra Heavy Duty Unison Feed Lockstitch Sewing Machine
-
